Coil Txiav rau Length Kab
Kev piav qhia
Technical Parameters
Taw qhia
Yog tias koj xav tau cov khoom zoo 1.0-4.0mm x 1650mm High Strength Stainless Steel Coil sheet straightening Cut to Length Line manufacturers & long-term oversea partner, please contact Jinye Complete Equipment!
Kev txhim kho kev tshaj lij tau dhau mus rau hauv Jinye. Cov neeg siv khoom los ntawm kev lag luam hauv tsev thiab thoob ntiaj teb tau qhuas txog Rotary Flying Shear Cut rau Length kab, uas yog cov kab ntau lawm uas txiav cov hlau kauj kom ntev tom qab uncoiling thiab leveling.
Technical Parameters
|
Tsis muaj. |
Yam khoom |
Specification |
|
1 |
Cov khoom nyoos |
Cov khoom siv hlau: SUS200, SUS300, SUS400 Input coil thickness: 1. 5-4 0 hli Input coil dav: min. 300mm, max 1650mm Tensile zog: 780N / mm2 max Tawm zog: 510N / mm2 Max Coil puab txoj kab uas hla: φ508mm / φ610mm Coil sab nraud txoj kab uas hla: 800-2, 000mm Coil hnyav: max 25, 000kgs. |
|
2 |
Daim ntawv tiav |
Stacker1: 300-4500mm ntev Stacker2: 300-10000mm ntev Stacking qhov siab: 650mm nrog pallet Max load: stacker1 5T, stacker2 7T. |
|
3 |
Tshuab parameters |
Ib qho mandrel uncoiler: φ508mm x 1650, 22KW AC Straightener: Φ70mm ua haujlwm yob, 17rolls 6Hi 180KW AC Pinch nro: ob khub ntawm yob φ 250mm × 1,800mm, 75KW AC Length ntsuas lub log: φ 95.49mm × 200mm, pub 5.5kw Rotary shear: 180KW servo AC, max 140 txiav / min |
|
4 |
Ua kom ceev |
1-3mm x 400mm, 125pcs, 50m / min 3mm x 500mm, 120pcs, 60m / min 1-3mm x 600mm, 133pcs, 80m / min 1-3mm x (1000-10000) hli, 80m/min 3-4mm x (1000-10000) hli, 40m/min |
Kev piav qhia txheej txheem ua haujlwm:
Crane nqa steel kauj los ntawm warehouse rau khaws eeb, coil tsheb xa cov kauj mus rau uncoiler mandrel los ntawm lub eeb, lub uncoiler muaj tsis siv neeg CPC muaj nuj nqi, nthuav lub uncoiler mandrel los kho steel kauj ntawm mandrel, dismantle lub strapping daim kab xev, uncoil kauj taub hau thiab xa nws mus rau pinch feeder, straighten daim ntawv kom tiaj tus los ntawm leveler, ces nro theem, sab qhia, ntug trimmer thiab seem winder, zaj duab xis thiab ntawv laminating, pinch feed sheet kom ya shear thiab txiav mus rau ntev, conveying siv txiav daim ntawv rau thawj stacker thiab thib ob stacker rau pawg nplooj ntawv mus txog tej pob khoom.
Tshuab precision:
Ntev ntev: ruaj khov ceev Tsawg dua lossis sib npaug rau ± 0.5mm / 2m, acceleration / deceleration Tsawg dua lossis sib npaug ± 1.5mm / 2m
Diagonal kam rau ua: ruaj khov ceev Tsawg dua los yog sib npaug rau ± {{0}}.5mm/2m, acceleration/deceleration Tsawg dua los yog sib npaug rau ± 0.65mm/2m
.burrs: hauv qab 1.
Flatness: dav tshaj 600mm 1.0mm thickness / 500mm ntev, flatness 0.2%
Stacking sib txawv: ± 2.0mm
Kev siv technology:
Hlau daim hlau yuav tsum tau ua los ntawm lub tuam txhab nto moo steel
ob daim hlau vuam ua ke, vuam seam qhov siab yuav tsum nyob rau hauv 2/3 ntawm tsawg thickness steel ntawv, tsis muaj vuam slag thiab txaws.
Txhua qhov chaw vuam yog xuab zeb blasting kho.
qhov tseem ceeb ntawm uncoiler, straightener, ntev feeder, ya shear yuav tsum tau annealing kho nyob rau hauv nruj ua lub sij hawm kom dhau mus tshem tawm kev ntxhov siab nyob rau hauv, ces CNC machining chaw rau tshuab cov khoom nyob rau hauv yuav tsum tau kam rau ua.
Ntxuav lub rooj ntawm cov cuab yeej machining, yog tias tsim nyog, ntxuav tawm qhov tawm ntawm lub rooj los ntawm oilstone. Lub workpiece yuav tsum ruaj khov, thiab cov kauj ruam kawg yuav tsum tau so. Nyob rau hauv 6-points positioning txoj cai, cov meters yuav tsum tau muab tso rau hauv peb cov lus qhia los xyuas seb lub workpiece puas tau loosened.
Nto pleev xim tsawg kawg yog ob zaug, cov xim yuav tsum yog lub teb chaws lossis thoob ntiaj teb nto moo hom.
